Sanden Eco Plus 160 Litre Heat Pump



Description Sanden Eco Plus 160 Litre Heat Pump



Sanden Eco® Plus Heat Pump - Leading hot water technology.

Sanden is a Japanese-owned global business that has earned a solid reputation as a leader in the field of heating and cooling technology.

Sanden Eco Plus 160 Litre complete heat pump system stainless steel tank, made in Australia.

Sanden’s “Eco®” Hot Water Heat Pump technology uses 1kW of energy to generate 4.5kW of heat; this is 78 per cent less energy compared to traditional hot water systems.

An environmentally advanced product that is affordable. It employs superior R744 (CO2) refrigerant technology, so that the amount of electrical energy required to heat the water is significantly less than that required by a conventional electric storage hot water system

For more information, contact us.



Models: GAUS-160FQS, GAUS-160EQTA, GAUS-160EQTAQ, GAU-A45HPC, GAU-A45HPA.

# Heat Pump Unit

✓ A high Coefficient of Performance (COP=4.5^) results in significantly reduced energy use and CO2 emissions

✓ Up to 50% faster heat recovery than currently available Hot Water Heat Pumps.

Whisper quiet operation, with industry leading noise level of 37dB - very neighbour friendly!

✓ Uses unique Ozone friendly R744 (CO2) refrigerant

✓ Simple installation by Plumber & Electrician, with no Refrigeration Mechanic required

✓ An automatic heating cycle, which makes it perfect for use with power generated by on-roof photo voltaic (PV) solar electric systems.

✓ 6 year Warranty, including parts and labour.

# Stainless Steel Tank

✓ Tank sizes 160 Litres.

✓ High quality, Australian made extra long life stainless steel cylinder.

✓ Fully insulated to stay warmer longer.

✓ Mains pressure rated.

160 Litres Tank with two installation options (tall with a reduced diameter or short with an increased diameter).

✓ Safety pressure and temperature relief valve supplied.

✓ 15 year Pro-rata Warranty, including parts and labour.

Sanden Eco Heat Pump - 15 year warranty on the water tank
 15 year Pro-rata Warrant





#The Price List is just for reference - Please contact us directly to get a more accurate price

Model
Number

Tank Size

Unit
Price
Before
Rebates

STC/RECs Rebates - ALL

VIC Metro
Elec Change
(VEEC's)

VIC Rural
Elec Change
(VEEC's)

Zone
 1

Zone
 2

Zone
 3

Zone
 4

Zone
 5

GAUS-315FQS

315Lt

$4190

26x

25x

32x

34x

32x

49x

52x

GAUS-300FQS

300Lt

$4110

26x

25x

32x

34x

32x

49x

52x

GAUS - 250EQTB

250Lt

$4090

26x

25x

32x

34x

33x

48x

51x

GAUS-160FQS

160Lt

$3990

26x

26x

31x

34x

33x

48x

51x

GAUS - 160EQTA

315Lt

$5100

26x

25x

31x

33x

33x

49x

52x

replacement heatpump

N/A

$3000

N/A

N/A

N/A

N/A

N/A

N/A

N/A

The Price List is just for reference - Please contact us directly to get a more accurate price

Specifications Sanden Eco Plus 160 Litre Heat Pump

Heat Pump

Dimensions GAUS-160FQS GAU-A45HPC GAUS160EQTAQ
Weight 48kg 48kg 48 kg
Technical
Heat Output (at 32.45 ºC ambient / 18.74 ºC cold water inlet) 4.99kW 4.99kW
Electric Input (at 32.45 ºC ambient / 18.74 ºC cold water inlet) 0.84kW 0.84kW 0.9kW
COP (at 32.45 ºC ambient / 18.74 ºC cold water inlet) 5.96^ 5.96^ 5.0^
Refrigerant CO2 (R744) CO2 (R744) R744(CO2)
Water Temperature Setting (Nominal) 63 ºC 63 ºC 60 ℃
Compressor Scroll, with Inverter Control Technology Scroll, with Inverter Control Technology Variable
Electrical Supply 240V/50Hz/Single Phase 240V/50Hz/Single Phase 220 – 240V/50Hz/1Ph
Operating Noise Level (measured 1m from HP unit) 37dB 37dB 37 dB
Ambient Air Operating Temperature Minus 10 ºC to Plus 42 ºC Minus 10 ºC to Plus 42 ºC -10 ºC to +43 ºC
Maximum Operating Water Pressure 700kPa
Water Connections & Settings
Inlet ½” BSP, 12.7mm ½” BSP, 12.7mm ½” BSP, 12.7mm
Outlet ½” BSP, 12.7mm ½” BSP, 12.7mm ½” BSP, 12.7mm
Country of Manufacture Japan Japan Japan
Warranty 6 Years*** 6 Years*** 6 Years***

Note: Materials and specifications are subject to change without notice

Storage Tank

Model No. GAUS-160FQS SAN-160SAQA GAUS160EQTAQ
Height 970mm 970mm 970mm
Hot Water Outlet & PTR Valve 753mm 753mm 753mm
Sensor Port 249mm 249mm 249mm
Cold Water Inlet / Heat Pump Flow 223mm 223mm 223mm
Diameter 621mm 621mm 621mm
Weight 29kg 29kg 29 kg
Storage Capacity 160L 160L 160L
Inner Tank Stainless Steel Stainless Steel Vitreous Enamel
Water Connections & Settings
Tank Relief Valve Setting (PTR Valve) 700(kPa) 850(kPa) 700(kPa)
Expansion Control Valve Setting (ECV) 600(kPa) 700(kPa) 600(kPa)
Maximum Mains Pressure Settings
With ECV 500(kPa) 500(kPa) 500(kPa)
Inlet Water Operating Pressure 500(kPa) 500(kPa) 500(kPa)
Adjustable Tempering Valve 1400(kPa) 1400(kPa) 1400(kPa)
Hot and Cold Connection Rp 20 (3/4″)
Female
Rp 20 (3/4") Female Rp 20 (3/4″)
Female
Watermark Licence No. WM-022333 WM-022333 WM-022333
Colour Surfmist & Ironstone Ends Surfmist & Ironstone Ends Colourbond Salt Bush
Country of Manufacture Australia Australia Australia
Warranty 15 Years Prorata*** (Excludes WA) 15 Years Prorata*** (Excludes WA)
