QUICK REVIEW
Powerwall 3 is a fully integrated solar and battery system that stores energy from solar production. It converts energy from solar panels, and its rechargeable battery pack provides energy storage for solar self-consumption, load shifting, or off-grid use. Powerwall 3 is installed with Backup Gateway 2 to control the system's connection to the grid and monitor home energy consumption.
Model Number: 1707000-31-J // 1707000-xx-y
Customer Interface: Tesla Mobile App
Warranty: 10 Years
In-built Solar Inverter A/C Rating: 5kW, 10kW, 11.04kW
Benefits of your Tesla Powerwall
Powerwall 3 is a fully integrated solar and battery system, designed to accelerate the transition to sustainable energy. Customers can receive whole home backup, cost savings, and energy independence by producing and consuming their own energy while participating in grid services. Once installed, customers can manage their system using the Tesla App to customize system behavior to meet their energy goals.
Powerwall 3 achieves this by supporting up to 20 kW DC of solar and providing up to 10 kW AC of continuous power per unit. It has the ability to start heavy loads rated up to 185 LRA, meaning a single unit can support the power needs of most homes. Powerwall 3 is designed for fast and efficient installations, modular system expansion, and simple connection to any electrical service.
Powerwall is compact, safe and includes a built-in battery inverter, which provides easier integration and over-the-air updates for new features and functions
✔️ Self-Powered Home : Use solar and Powerwall to reduce reliance on the grid and run your home off solar day and night.
✔️ Energy Savings: Reduce your power bills by charging during off-peak times
✔️ Backup Power: Protect your home from a power outage with seamless and reliable backup power
✔️ Home Energy Control: Manage and control your home energy use in real-time with the Tesla mobile app
How does the Tesla Powerwall Work?
1 - Solar begins powering your home in the morning when the sun rises.
2 - Excess solar energy charges your Powerwall.
3 - Powerwall runs your home at night.
First Powerwall 3 installed in Canada May 2024
Testimonials
What they are saying about us
F.A.Q
Frequently Asked Questions
-
Why does the Tesla mobile app show power flows or values that appear inaccurate?
Power flow on the monitoring Tesla mobile app shows the instantaneous flow of power of your home energy system. On a typical day a combination of solar, grid, and Powerwall may be powering your home. Solar energy may flow to the grid when your home does not need it and Powerwall is full. When charging your Powerwall to its backup reserve level or in Backup-only mode, solar power will flow directly from solar to Powerwall while grid energy is drawn for the home.
-
Tesla mobile app - log in / set up / learn more
Once your Powerwall has been turned on, download the Tesla app and start monitoring your Powerwall and home energy usage.
Step 1: Log In
Log in using the same email address you used to order Powerwall with solar. If you are already a Tesla vehicle owner, log in using the same email address you use to sign into your Tesla Account.Step 2: Set Up Notifications
Receive notifications when Powerwall starts backing up your home during instances such as a power outage.Step 3: You are now logged into the Tesla app
Learn more about the features of the Tesla mobile app. You can also learn more about using and customizing your Powerwall below:
Power Everything
Powerwall reduces your reliance on the grid by storing your solar energy for use when the sun isn’t shining. Use Powerwall alone or combine it with other Tesla products to save money, reduce your carbon footprint and prepare your home for power outages. In addition, Tesla operates Australia's largest Virtual Power Plant, a network of homes to support the grid with clean renewable energy.
💡 Power Your Home
🔋 Recharge with clean energy when paired with solar
Backup Protection
Powerwall is a battery that stores energy, detects outages and automatically becomes your home's energy source when the grid goes down. Unlike generators, Powerwall keeps your lights on and phones charged without upkeep, fuel or noise. Pair with solar and recharge with sunlight to keep your appliances running for days.
🔆 Store Energy
24/7 Backup Protection
Use stored energy to power your home during an outage
Keep appliances running with little interruption
Monitor and Optimise
With the Tesla app, you can monitor your home’s energy production and consumption in real time. Set your preferences to optimise for energy independence, outage protection or savings. With instant alerts and remote access, you can control your system from anywhere.
💲 Customise settings for personalised savings
24/7 Stay connected with instant alerts before severe weather
📱 Manage your energy
Modern and Compact
With easy installation and a minimalist design, Powerwall complements a variety of home styles. The compact, all-in-one construction features versatile mounting options for indoor or outdoor spaces.
✅ Child and pet friendly with no exposed wires or hot vents
10x Stack up to 10 Powerwalls together to meet your needs
☔️ Water resistant and tough for all weather conditions
Recent Powerwall 3 install in Texas US
Powerwall 3 includes the following components and features:
Component/Feature | Name |
1 | LED Indicator |
2 | On/Off Switch |
3 | Integrated DC Isolator |
4 | Air Intake |
5 | Air Exhaust |
Typical System Layouts
Whole Home Backup
A Powerwall 3 system for whole home backup is designed to store energy from the grid or solar, and power the entire home during a grid outage.
Partial Home Backup
A Powerwall 3 system for partial home backup is designed to store energy from the grid or solar, and can power some home loads during a grid outage. These loads are selected during the system design phase, and the installer configures the system at installation to exclude all other loads from backup.
System Technical Specifications
Nominal Grid Voltage (Input & Output) | 230 VAC |
Grid Type | Single phase |
Frequency | 50 Hz |
Nominal Battery Energy (Values provided for 25°C (77°F), at beginning of life. 3.3 kW charge/discharge power.) | 13.5 kWh AC |
Nominal Output Power (AC) | 5 kW 10 kW 11.04 kW |
Maximum Apparent Power | 5,000 VA 10,000 VA 11,040 VA |
| Maximum Continuous Current | 21.7 A 43.5 A 48 A |
Overcurrent Protection Device | 32 A 50 A 63 A |
Maximum Continuous Charge Power | 5kW |
Output Power Factor Rating | 0 - 1 (Grid Code configurable) |
Maximum Output Fault Current | 160 A |
Maximum Short-Circuit Current Rating | 10 kA |
Load Start Capability | 185 locked rotor amps (LRA) |
Power Scalability (The maximum number of Powerwall 3 units per installation may vary by market.) | Up to 4 Powerwall 3 units supported |
Solar to Battery to Home/Grid Efficiency (Typical solar shifting use case. Values provided for 25°C (77°F), at beginning of life. 3.3 kW charge/discharge power.) | 89% |
Solar to Home/Grid Efficiency (Tested using CEC weighted efficiency methodology.) | 97.5% |
Supported Islanding Devices | Backup Gateway 2 |
Connectivity (Cellular connectivity subject to network service coverage and signal strength.) | Wi-Fi (2.4 / 5 GHz), Ethernet, Cellular (LTE/4G) |
Hardware Interface | Dry contact relay, Dynamic Response Mode Interface, RS-485 for meters |
AC Metering | Revenue Grade (+/- 0.5%) |
Protections | Integrated arc fault circuit interrupter (AFCI), Isolation Monitor Interrupter (IMI), Integrated DC Isolator |
Customer Interface | Tesla Mobile App |
Warranty | 10 years |
Solar Technical Specifications
Maximum Solar STC Input | 20 kW |
Withstand Voltage | 600 V DC |
PV DC Input Voltage Range | 60 — 550 V DC |
PV DC MPPT Voltage Range | 60 — 480 V DC |
MPPTs | 3 |
Maximum Current per MPPT (IMP) | 26 A |
Maximum Short Circuit Current per MPPT (ISC) | 30 A |
Mechanical Specifications
Dimensions (These dimensions include the glass front cover being installed on Powerwall 3.) | 1105 x 609 x 193 mm | |||
| Weight | 130 kg | |||
| Mounting options | Floor or wall mount | |||
Environmental Specifications
Operating Temperature | –20°C to 50°C |
Operating Humidity (RH) | Up to 100%, condensing |
Storage Temperature | –20°C to 30°C, up to 95% RH, non-condensing, State of Energy (SOE): 25% initial |
Maximum Elevation | 3000 m |
Environment | Indoor and outdoor rated |
Enclosure Rating | IP55 |
Ingress Rating | IP67 (Battery & Power Electronics) |
IP55 (Wiring Compartment) | |
Pollution Rating | PD3 |
Operating Noise @ 1 m | < 50 db(A) typical, <62 db(A) maximum |
Environmental Requirements
Powerwall 3 is capable of charging and discharging within the operating temperature range specified below. At the extremes of the temperature range, Powerwall 3 may limit charge or discharge power to improve battery lifespan.
For best performance, the average ambient temperature over the system’s lifetime should fall within the optimum temperature range specified below.
Operating Temperature | -20°C to 50°C* |
*Powerwall 3 is designed to operate in all climates and in direct sunlight, from temperatures of -20°C to 50°C. Performance may be de-rated at operating temperatures above 40°C.
Care and Cleaning
Keep the immediate area around Powerwall 3 clear of foreign objects and debris to maintain optimal airflow.
! CAUTION
Do not lean on, stack anything on top of, or hang anything from Powerwall 3 or from wires or conduit leading to Powerwall 3.
! CAUTION
To clean Powerwall 3, use a soft, lint-free cloth. If needed, the cloth can be dampened with mild soap and water only.
! CAUTION
Do not use cleaning solvents to clean Powerwall 3 or expose Powerwall 3 to flammable or harsh chemicals or vapors.
Maintenance
Powerwall 3 does not require pre-scheduled preventative maintenance. The only maintenance required by an owner is to keep the Powerwall unit free and clear of debris, especially around the air intake and exhaust.
The owner is responsible for ensuring the Powerwall system is operational; this can be confirmed by the white LED on the front of Powerwall 3, or in the Tesla mobile app.
Note
If the Powerwall system is not operational for an extended period of time, this may result in damage to your system and void your Powerwall warranty.
