SolarEdge S500B Power Optimiser
GET A FREE QUOTE
QUICK REVIEW
Maximize the energy output of each solar module and counteract all forms of module mismatch-loss, including those due to manufacturing tolerances, partial shading, and aging.
Model Number: S500B-1GM4MRM
Designed to accommodate high-voltage panels, this device supports an input power of 500Wp, a short-circuit current (Isc) of 15A, and an input voltage of 125V.
- Specifically designed to work with SolarEdge inverters
- Detects abnormal PV connector behavior, preventing potential safety issues*
- Module-level voltage shutdown for installer and firefighter safety
- Superior efficiency (99.5%)
- Mitigates all types of modules mismatch- loss, from manufacturing tolerance to partial shading
- Flexible system design and compatible with bifacial PV modules for maximum space utilisation
- Faster installations with simplified cable management and easy assembly using a single bolt
- Next generation maintenance with module safety
S-Series Power Optimizers
Introducing SolarEdge's most sophisticated Power Optimizer to date. The latest S-Series Power Optimizers are expertly designed to handle the diverse Australian climate, featuring enhanced safety, streamlined wiring, and intelligent remote monitoring capabilities. They continue to:
Enhance panel-level output through DC optimization, even in the presence of shading or debris.
Provide complete system transparency with panel-level monitoring.
Accommodate higher wattage panels with reduced clipping, maximizing power density.
SolarEdge DC-Optimised Technology | Microinverter Technology Clipping |
 |  |
|
|
How Do Power Optimizers Function?
A solar panel power optimizer is an essential component of any solar energy system, crafted to boost the efficiency and performance of each panel. Traditional systems connect panels in series, where the performance of the entire array can be degraded by a single underperforming panel. In contrast, power optimizers enable each panel to operate independently. This feature is particularly advantageous when panels are shaded, dirty, or oriented differently from others in the array.
Power optimizers are affixed to individual solar panels, where they convert the DC electricity produced into optimized voltage and current. This optimized DC power is then relayed to a central inverter, where it is converted into AC power for use in homes or for feeding back into the grid. By maintaining each panel at its optimal power point, power optimizers enhance energy yield and overall system efficiency.
SolarEdge Power Optimizers incorporate leading-edge technologies such as module-level optimization to prevent energy loss through clipping, and SafeDC™, which reduces DC voltage to a safe level during inverter or grid shutdowns. This significantly lowers the risk of electrical hazards during maintenance or emergency situations.
Enhanced Safety Features
SolarEdge Sense Connect represents a pioneering advancement in the industry, designed to detect abnormal thermal events within the Power Optimizer connectors, effectively preventing the formation of electric arcs.
Proactively identifies potential arc threats and halts power flow.
In response, the inverter transitions the system to a safe mode and lowers the voltage.
The location of the faulty connector can be pinpointed within the system layout displayed on the Monitoring Platform.
Event notifications are promptly delivered through SetApp and the Monitoring Platform.
Streamlined Wiring Solutions
Optimize cable lengths for more efficient wire management.
Minimize exposure to potential isolation faults, enhancing safety and reducing maintenance requirements.
Testimonials
What they are saying about us
F.A.Q
Frequently Asked Questions
-
How to reconnect Wi-Fi for my SolarEdge Inverter?
Your SolarEdge inverter may have disconnected from the internet - for example a change in the modem/router, change in ISP provider, etc.
To update the Wi-Fi settings on your SolarEdge inverter - follow these steps:
- Download the 'MySolarEdge' app > Android and Apple iPhone
- Log-in with your username and password
- Select 'Inverter communication'.
- Select 'Configure'.
- Select 'Connect with WPS' or choose your home network from the available networks.
- Type your password, then select 'Join'.
SolarEdge's latest S-Series Power Optimizers are exceptionally suited for the diverse Australian environment, providing cutting-edge safety, streamlined wiring, and intelligent remote monitoring capabilities. They enhance solar installations by:
Increasing panel-level energy production through DC optimization, even in conditions of shading or debris.
Ensuring complete visibility of system performance with panel-level monitoring.
Accommodating higher wattage panels with minimal power clipping for optimal power density.
SolarEdge DC-Optimized Technology
Maximizes power output from each module and mitigates effects of shading.
Prevents module-level power clipping to enhance overall power generation.
Enables detailed monitoring of each panel's power output via the mySolarEdge app.
Superior Safety
Proactively identifies potential arc threats, halting power flow to prevent incidents.
The inverter transitions the system to safe mode, lowering voltage to safeguard components.
Pinpoints faulty connector locations within the system layout on the Monitoring Platform.
Sends event notifications through SetApp and the Monitoring Platform for immediate action.
Simplified Wiring
Optimizes cable lengths for more efficient wire management.
Reduces risks associated with isolation faults, thereby increasing safety and decreasing the need for maintenance.
Rated Input DC Power: 500W
Absolute Maximum Input Voltage (Voc): 125V
MPPT Operating Range: 12.5 - 105 V
Maximum Short Circuit Current (Isc): 15 A
Maximum Efficiency: 99.5%
Weight Efficiency: 98.8%
Minimum String Length (Power Optimisers): 6
Maximum String Length: 25
Maximum Nominal Power per String: 5700W (6000W if with SE8250H / SE10000H)
